| DN4 | OD9.53 | 95mm-10.5mm | 1/8" | 0,003-0,142 m³/h
0,047-2,374 l/min
0,013-0,627 gal/min |
| DN8 | OD12.7 | 12,4mm-13,1mm | 1/4" | 0,011-0,570 m³/h
0,190-9,496 l/min
0,050-2,509 gal/min |
| DN10 | OD15 | 14,5mm-15,4mm | 3/8" | 0,026-1,282 m³/h
0,427-21,366 l/min
0,113-5,644 gal/min |
| DN15 | OD20 | 16,5mm-23,0mm | 1/2" | 0,046-2,279 m³/h
0,760-37,984 l/min
0,201-10,034 gal/min |
| DN20 | OD25 | 25,0mm-30,0mm | 3/4" | 0,103-5,128 m³/h
1,709-85,464 l/min
0,452-22,577 gal/min |
| DN25 | OD32 | 32,0mm-35,0mm | 1" | 0,182-9,116 m³/h
3,039-151,935 l/min
0,803-40,137 gal/min |
| DN32 | OD40 | 38,0mm-45,0mm | 1-1/4" | 0,285-14,244 m³/h
4,748-237,399 l/min
1,254-62,714 gal/min |
| DN40 | OD50 | 48,0mm-54,0mm | 1-1/2" | 0,410-20,511 m³/h
6,837-341,854 l/min
1,806-90,309 gal/min |
| DN50 | OD63 | 58,0mm-64,0mm | 2" | 0,729-36,464 m³/h
12,155-607,741 l/min
3,211-160,549 gal/min |
| DN65 | OD75 | 72,0mm-78,0mm | 2-1/2" | 1,140-56,976 m³/h
18,992-949,595 l/min
5,017-250,857 gal/min |
| DN80 | OD90 | 80,0mm-92,0mm | 3" | 1,641-82,045 m³/h
27,348-1367,417 l/min
7,225-361,234 gal/min |
| DN100 | OD110 | 108,0mm-116,0mm | 4" | 2,917-145,858 m³/h
48,619-2430,963 l/min
12,844-642,194 gal/min |
| DN125 | OD140 | 132,0mm-142,0mm | 5" | 4,558-227,903 m³/h
75,968-3798,380 l/min
20,069-1003,429 gal/min |
| DN200 | OD220 | 218,0mm-228,0mm | 8" | 11,669-583,431 m³/h
194,477-9723,852 l/min
51,376-2568,778 gal/min |
